CKMDefence Hydraulic Road Blocker is the most widely used system in areas where entry and exit should be controlled and safe against all kinds of vehicle attacks, such as military facilities, government buildings, embassies, production facilities, oil refineries, hotels, airports, and stadiums.
The system is specifically designed against vehicle impacts, and its components have been reinforced to be effective in all possible attack scenarios.
Thanks to its hydraulic operating system, the CKMDefence Road Blocker System works continuously even in the busiest places. Additionally, CKMDefence Security Road blocker crash tested and certified for IWA 14-1:2013 / PAS68 with anti-terror capability.
This system synchronizes with other security systems such as swing barriers, rising bollards, etc., keeping the defense at the highest level in case of attack, while allowing authorized vehicles to safely enter the area. It can be integrated with all kinds of Access Control Systems such as Plate Recognition Systems, HGS (Electronic Toll Collection-Fast Pass) Systems, Card Readers.
TECHNICALFEATURES
|
Unit operating voltage |
380VAC, 3-Phase, 50/60 Hz |
|
Length |
3111 mm – 4111 mm – 5111 mm – 6111 mm ±20 mm |
|
Height above ground |
780 mm ± 10 mm |
|
The part burried under the ground |
1050mm ±10 mm |
|
Width |
1350mm ± 10 mm |
|
Color |
Yellow Black Painted (RAL 1028 , 9005) |
|
Collisionunit |
Steel Sheet and NPUNPI steel bar construction |
|
Wall thickness |
10 mm |
|
Surface coating |
Elektrostatic painted |
|
Corrosion coating |
Shot blasting, epoxy under coating, elektrostatic painted |
|
Turn On/off time |
4-6 sec. |
|
Emergency take off Feature |
2 – 3 sec. (optional) |
|
Turn on/off capacity |
1000 / gün |
|
Power Engine |
4kw – 5kw , 380V AC, 3-Phase |
|
Operating temperature range |
-25 / 60 °C |
|
Work system |
Hydraulic sistem |
|
|
|
|
Hydraulic piston |
2 qty |
|
Hydraulic powe unit |
Industrial hydraulic pump, oil level and temperature gauge, manual hand pump |
|
Automation routing |
220V two way solenoid valve |
|
Hydraulic pressure |
40-80 Bar |
|
Hydraulic tank |
30-50 liter |
|
Hydraulic hose |
R2 3/8 330 Bar hose |
|
Hydraulicoil |
46 no.hydraulicoil |
|
Hydraulic system heating/cooling |
Oil heater/cooler (optional) |
|
Control Cabinet |
Cabinet Dimension: 900 x 900 x 700 mm (height, lenght, depth) |
|
Control system |
Remote control,button control (optional), access systems (optional) |
|
Control Panel |
Compatible with PLCbase control, micro process control card, |
|
Manual Usage |
Manuel hand pump |
|
Warning equipment |
Warning light (optional), trafik lamp (optinal), soundwarning (optional) |
|
Protection System |
Loop detector, fotocell (optional) |
|
Drain pump |
Optional concrete |
|
Infrastructure |
C35 concrete |
|
Power failure working status |
Battery (optional) |
